Metal Seat DI Body Gate Valve

Specifications:

  • Size: DN40-DN400

  • Pressure: PN10/PN16

  • Standard:  EN593, DIN 2501 PN6/10/16, DIN3202 F4

Materials:

  • Body : Cast Iron

  • Seal : Cast Iron+PTFE

  • Stem : Stainless Steel 304

Characteristic:

  • Medium: Water, Oil, Gas

  • Temperature: -20-200℃

Detail / Feature / Application

Detail / Feature / Application

  • No groove design at the bottom of the valve prevents the leakage or damage caused by theaccumulation of the valve, this design also has small resistance to the fluid.

  • Non-rising resilient seated gate valves solve the problem in general gate valves such asleakage, rusting etc.

  • LSimpler structure, better workmanship and shorter face to face dimension.

  • Application: Pipelines to convery oil and storage facilities, Water and wastewater technology, The wellhead device of the oil and gas expoitation, Water engineering.

  • Each product will be carried out appearance, material, air tightness, pressure and shell testingbefore leaving the factory ;unqualified products are resolutely not allowed to leave the factory.
